live scan fingerprint scanner Bio8Plus

The Live Scan fingerprint scanner Bio8plus is a biometric device used for capturing and digitizing fingerprints. It is commonly used in law enforcement agencies, government organizations, and private companies for criminal identification, background checks, and employee screening.

The bio8plus scanner is known for its high-quality image capture, accuracy, and ease of use. It uses optical sensors and advanced image processing algorithms to produce clear and detailed fingerprint images. The device is designed to minimize false rejections and provide reliable results.

The scanner connects to a computer or other compatible device via USB or Bluetooth, allowing for seamless integration with fingerprint recognition software or database systems. It is typically accompanied by software that enables the management and analysis of fingerprint data.

The Live Scan fingerprint scanner bio8plus is a reliable tool for biometric identification and is widely used in various industries where accurate and efficient fingerprint capture is required.

Live Scaner Bio8P Function

The Multifinger Scanner DactyScan84c is a compact and FBI app. F certifed 10-print livescan in full compliance with the”10-print capture scanner & software user group requirements” suitable for all applications in need of 4-slaps and rolled acquisition.

FBI APP. F Certifed

The Multifinger Scanner DactyScan84c is a 3.2” x 3.0” 10-prints and rolls Livescan at 500 dpi certified by the FBI according to FBI IAFIS IQS App. F. as Livescan System as well as for Identification Flats

10-Prints and Rolled Acquisition

With up to 27 frames per second for 4-slaps and up to 25 frames per second for rolled prints acquisition the Multifinger

Scanner DactyScan84c is unique in terms of acquisition speed. An ergonomic design combined with an easy-to integrate SDK architecture makes the Multifinger Scanner DactyScan84c the perfect choice for system integrators and solution providers.

A user interface based on 12 three color leds facilitates the acquisition procedure by indicating the fingerprint(s) to be acquired and providing quality feedback thus eliminating the necessity for skilled operators and therefore increasing workfow efficiency.

The Multifinger Scanner DactyScan84c is available as OEM module for all system integrators looking for a compact 10-print Livescan to be physically integrated in embedded solutions.

Spoofing and Liveness Detection

As optional module, Multifinger Scanner DactyScan84c can be upgraded with a leading edge SW solution detecting fake fingers made with various different materials. Device add-on can be used on existing Multifinger Scanner DactyScan84c as well as on new installations.

Multiscan SDK Features
AUTOMATIC SEQUENCE CHECKING	guarantees a correct scanning sequence
ROLLED FINGERPRINT CAPTURING	displays in real-time, self-adaptive to rolling speed and directions,seamless composite image generation, automatic stop detection
SEGMENTATION:	automatic segmentation of four- slap and two thumbs fingerprint images in single flat images
CORRECT POSITION AND SLAP COMPLETENESS CHECK:	Checks for correct finger placing; checks for incomplete slaps due to missing fingers.
SLIDE DETECTION FOR FLAT PRINTS	detects deformations of fingerprints due to sliding during acquisition
STANDARD OUTPUT FORMAT	Creation of “ANSI/NIST-ITL-1-2007/2011” type 1, 2, 4 and 14 records – EFTS71 output format support.
ELIMINATION OF LATENT PRINTS	elimination of latent prints originated from recent scans.
AUTOMATIC ACQUISITION START AND STOP	sensing of fnger placement and automatic acquisition of the image with the highest quality. Quality thresholds for images can be set through the Multiscan SDK
HALO ELIMINATION：	elimination of halo due to moist fngerprints during acquisition
IMAGE QUALITY CHECKING:	dynamic estimation of fingerprint image quality during scanning process; NISTIR7151 quality check.
IMAGE COMPRESSION	FBI certified WSQ compression; further compression formats available are jpeg and jpeg2000.
Technical Data
ACTIVE SCANNING WINDOW	Flat four fngers up to 3,2” x 3,0” – Two flat thumbs up to 3,2” x 3,0” -Rolled finger up to 1,6” x 1,6” – 500 dpi
INTERFACE：	USB 2.0
IMAGE QUALITY AND FORMATS：	FBI IAFIS IQS Appendix F (FAP60) certified ANSI/NIST-ITL 1-2007/2011 ISO/IEC FCD 19794-4 ANSI/NIST-ITL 1-2000 ANSI/NIST-ITL 1-2000 Interpol Implementation
TEMPERATURE	Storage: from -20°C to +60°C – Operating: from +0°C to +50°C
HUMIDITY：	From 10 to 90% (non-condensing)
DIMENSIONS：	Flat Top Version: 148 x 152 x 121 mm Standard Top Version: 148 x 152 x 148 mm
WEIGHT	1.4 Kg
SUPPORTED OPERATING SYSTEMS	Microsoft Windows up to Win10 in 32-bit and 64-bit configuration Linux Ubuntu and Fedora distributions in 32-bit and 64-bit configuration Android
CERTIFICATIONS	CE, FCC, RoHS, KCC

Easy to Use

Support Windows , Android System

Certified Image Quality

With FBI certification from the U.S. Federal Bureau of Investigation, data is safe and secure

High Speed

High recognition accuracy and small error. 2 seconds to authenticate and compare

Bio8 plus Live Scan fingerprint scanner for backhround checks

Ten Fingerprint Scanner App
